16-Socket Automated IC Programmer
16-Socket Automated IC Programmer

Smart 16chips 2nozzles Automated Programmer Superpro Sb05e



    16-Socket Automated IC Programmer

    "24/7 Automated Programming Workhorse"

    Superpro 5e is a automatic IC programmer with high performance and reasonable price for large-scale electronic product manufacturing. This programmer can automatically pick up, place, program, take out and pack up chips. With fully automated operation setup capabilities, it can improve working efficiency and minimize human errors. Superpro 5e comes with daul pick & place nozzles, 4 independent socket pressing actuators, two CCD cameras and can work with 2 tape feeders. Up to 2000 units per hour (UPH) for devices with programming time less than 50 sec. Suitable for both small and large capacity devices.

    The value of a programming product is a combination of price, the number of devices supported, programming speed, regular update of devices, free downloads, and reliability. Xeltek products are designed with the above factors in mind which provide the best value in the industry.


    More related articles


           5 YRS of free service                Case study          Using a barcode scanner



        Operating Superpro remotely     Supporting more than 102,000 devices     Competitor comparison



    Varied I/O devices


    Manual Tray (Standard equipped) Standard I/O device of the machine. Operator will replace the programmed tray from the Superpro machine manually after the full tray is programmed. Customer does not need to buy any other accessory while using this option.

    Auto Tray Device This device is an extension of the fixed tray. It includes tray-in and tray-out and users can put 20 trays into the device. When the machine is running, users can add trays or take out trays without stopping the machine. The auto tray device can also be installed outside of the whole machine and trays can be automatically changed without the need to open the upper cover, which saves tray changeover space and avoid human error during tray changeover. The auto tray device can stack up to 20 JEDEC trays.

    Tape-In Device Electric Tape in feeder. Tape width between 8 and 32mm applicable. Tape-in device can be configured as per the chip to be programmed. For SOIC and TSOP packages customer will need 2-3 types of different tape in the devices depending on the width of chips to be programmed.

    Tape-Out Device Connects to a Superpro 5e or Superpro 3 for fully automatic operation. 8-32 mm tape widths can be used with the device. Output reel is sealed with heated tape.

    Tube-In Moves chips in the machine. Chip guider for different chip width (optional). IO is multi feed and upto 8 tubes can be operated at once (optional). Tube IO pages should also be updated accordingly.

    Tube-Out Moves chips out of the machine. Chip guider for different chip width (optional). IO is multi feed and upto 8 tubes can be operated at once (optional). Tube IO pages should also be updated accordingly.

    Laser Marker System An optional attachment to the tape-out or the auto tray device for high speed marking. It marks up to 4 characters on the passed chips.

    Tape Ink-Marker Add-on item for tape out machine. On completion of programming the chip can be automatically marked with a point using ink (optional).   Tray Ink Marker Add-on item for auto tray machine. On completion of the programming the chip can be automatically marked with a point using ink (optional).



    Advantages of Superpro -5e

    High Throughput Superpro 5e is based on a high performance servo system that can program up to 2000 UPH (units per hour) (for devices with programming time less than 50 sec) and is suitable for both small and large capacity devices. Throughput is up to 60 times higher than Superpro 1, especially higher for large capacity devices like eMMC, NAND/NOR FLASH, SPI FLASH. It can be operated 24x7 and can provide throughput of 1,728,000 UPM (units per month). One person can supervise many Superpro machines and once they are programmed they can usually be left to operate by themselves.
    High Performance Programmers Superpro 5e is equipped with four SuperPro 7500N high speed universal programmers. Depending on the device programmed, each SuperPro 7500N can have up to 4 sockets with a total of up to 32 sockets in the system. Most programmers in the market use technology which is up to 10 years old. The best current hardware technology is to use a high speed MCU chip built inside the programmer. SuperPro 7500N programmers employ a very high-speed MCU chip producing not only reliable programming algorithms but also increasing programming speed. Utilization of ARM11 32bit MCU combined with an internal Linux operating system makes them the most advanced and versatile programmers in the industry.
    LAN Operation Most volume programming applications need programmers to be operated remotely and this can be achieved by using the LAN port on Superpro programmers. Programmers can be connected to a local network and be remotely controlled by any computer on the network via LAN (100M) port. LAN port enables remote project loading, quality monitoring, volume control, file security. Technical department can remote control programming operations and processes, including downloading project file, command execution, project settings, and obtain real time information to achieve production goals. Remote network management provides the most protection for intellectual property. Project data and files are never shared with operators because files are remotely loaded by authorized engineers.
    The Most Durable and Reliable Systems in the Industry China is the hub of the world Electronics manufacturing and Xeltek automated programmers are widely installed at most major Electronic manufacturing plants with multiple installations at many locations. Most companies run production 24 hours/day and 7 days/week programming millions of devices per year. Xeltek automated programmers have been refined to run non-stop, withstand harsh and battle-ground like environment.
    Largest Device Support Located in Silicon Valley, we keep good relationships with many major IC companies that are important for us to continuously support new devices. Xeltek currently supports more than 100,000 devices, which is the largest device library in the programming industry. Requested device algorithms can be added within a week - average lead time from other manufacturers is over two months.
    Better Yield Our semiconductor manufacturer approved algorithms, precision and clean signals guarantee high programming yield. Algorithms are performed with state machine architecture constructed with FPGA to achieve an ultrahigh programming speed. Along with the low voltage components selection, they program devices down to 1.2 volts.
    Chip Size Devices between 2x2mm to 30x30mm can be programmed. Superpro 5e supports the SOT23 package which measures only 2x3mm. We do not know of any other manufacturer who supports such a small package type and this is a testimony that Superpro 3 excels in its accuracy and precision.
    Powerful and Intelligent Software User-friendly software with graphical interface cuts learning curve. Setup data saved for next operation. Software also includes resourceful log table, convenient production and quality tracking, authorization, flexible stopping strategy for bad socket or module.
    Lowest Cost Automated Programming System in Market: The Most Affordable and High Value Systems in the Industry. High volume and extensive production experience enables the products to be the most competitive in quality, price, and value in the industry
    Short change-over time I/O devices and socket adapters are easily interchangeable and socket positioning can be performed automatically. Auto Tray and Tape-out can be permanently attached to Superpro eliminating changeover time when moving from tape-out to auto tray. Tape-in feeder changeover time is below 10 minutes and laser marker changeover time between tray to tape is under 15 minutes.
    Socket Cost and Investment Cost recovery in short period with low investment in the beginning as socket adapters are universal for up to 144 pin chips. For most of competitor programmers, user has to invest on device specific socket adapters for chips greater than 48 pins thus increasing cost in long term.
    Technical Support More than 30 engineers are devoted to developing new programmers, socket adapters and device algorithms. Engineers are fluent in English and provide excellent direct support through emails, telephone, live chat an online ticketing system. With our locations in the United Stated and China, providing 17 hours of continuous support worldwide daily, we are confident to be able to provide support anywhere in the world.

  • All orders received before noon Beijing Time will begin processing the same business day.

    Device Updates:

  • XELTEK updates software and device algorithm regularly.
  • View the latestDevice List .
  • Download the current software version free of charge .
  • Updates are available by mail at a nominal charge.
  • XELTEK also adds devices upon customer's request at its option.

    Warranty Support:

  • Programmer is warranted to be free of manufacturing or workmanship defects for one year from the date of purchase.
  • Online Technical Support is also available 24 hours or you may call us during our business hours through Friday 8:30am to 5:30pm (Beijing Time).

  • Hardware & Electrical Specifications:

  • Supported devices: EPROM, Paged EPROM, Parallel and Serial EEPROM, FPGA Configuration PROM, FLASH memory (NOR & NAND)n, BPROM, NVRAM, SPLD, CPLD, EPLD, Firmware HUB, Microcontroller, MCU .
  • PC interface: USB2.0,LAN
  • Stand-alone Feature: None
  • Electrical spec. of the AC adapter: AC 220V , output AC 220V ; power:1.5kW
  • Mechanical parameter: Main unit: Size: 1260 × 900× 1550 mm Weight: 248Kg.
  • Packing Box: Size - mm Weight: - Kg.

  • Accessories:

  • MainUnit (contain 4 unit SUPERPRO/7500N programmer), Industrial Personal Computer, User's Guid, Software CD-ROM, Warranty Card.
  • Optional Accessories: Auto/Half-Auot Tray In/Out ,Tape In/Tape out ,Tube In/Out Device, Adapter;
